Mesin Hot Splicing EPNUO adalah mesin untuk melakukan penyambungan belt conveyor.
Mesin Hot Splicing Ini dapat berguna sebagai :
Strip-Tear-Repair-Vulcanizing-Press
PVC/PU-Belt-Vulcanizing-Press
Ply-Splitter
Belt-Finger-Puncher
Belt-Cutter-Machine
PVC/PU-Belt-Welding-Baffle
Belt-Skiving
PVC/-Transmission-Belt-Vulcanizing-Press
Escalators-Conveyor-Belt-Vulcanizing-Press
Conveyor-Belt-For-Textile-Machine-(splndle-tape)
Service
Spesifikasi Mesin Press HOT SPLICING EPNUO :
1. Power Voltage: 380V. 525V. 480V. 440V. 415V. 400V or 220V
2. Vulcanizing pressure: 100-200PSI (6~14kg / cm2) (Determined by detailed rubber belts)
Other vulcanizing pressure can also be available at negotiated price.
3. Vulcanizing temperature: 145℃ (adjustable 0~200℃)
4. Temperature-rising time (from normal temperature to vulcanizing temperature): no more than 35 min
5. Cooling time: 10-15min
6. Time of heat preservation for vulcanizing could be adjusted according to thickness of rubber belt
7. Standard length of the heating plate is 840mm. Other size of heating plate also available,455mm,480mm,660mm,710mm,940mm,1015mm,1065mm,1115mm,etc.
CARA MELAKUKAN HOT SPLICING
Adapun Cara Melakukan Hot Splicing Conveyor Belt:
1. Kupas Top dan bottom Belt Conveyor
2. Buat Step Sambungan sesuai Step Table Tensile Strength
3. Kuaskan Solution pada carcass.
4. Pasangkan tie gum lalu kuaskan solution pada tie gum
5. pasangkan top cover pada cover belt yg telah dikupas
6. pasangkan mesin pada area hot splicing
7. lakukan cooking dengan mesin press.
8. Setelah selesai proses curing time mesin dapat dibongkar dan selesai.
Lebih lanjut mengenai cara penyambungan belt dapat melihat artikel : Cara Hot Splicing Conveyor Belt type Fabric
MATERIAL HOT SPLICING
Material yang jadi kebutuhan saat melakukan penyambungan belt Hot Splicing:
- Tie Gum / Intermediet Rubber
- Top Cover atau cover stok
- Solution STL RF
- Solvent
- Silicon Paper
DAFTAR TOOLS yang perlu anda siapkan saat melakukan penyambungan hot splicing:
Belt tensioners
Chain winch
Screw clamps
Measuring tape
Metal ruler
Flat angle
Plmb line
Marking crayon (white)
6″ knife
Don Carlos knife Off-set knife Ply knife
Ply lifter
Whetstone
Scissors
Pincers
Grip tongs
Hand brush & Contour Wheel Buffing Tool
Cement brush
Stitcher
Cable drum
Rubber Cut or
Branding iron
Buffing motor (with flexible shaft and wire brushes)
Off-set knife
Ply knife
Safety goggles
Drying hood
Kami menyediakan splicing tools tesebut. silahkan hubungi kami untuk mendapatkan informasi lebih lanjut.
